Aseptic Filling Systems

Our aseptic filling systems enable filling in a sterile environment, making them ideal for low-acid beverages such as tea and dairy-based drinks.
Shibuya’s aseptic filling technology is highly trusted worldwide, with over 150 systems installed globally, including systems that have received U.S. Food and Drug Administration (FDA) clearance.
Recognized as one of the world's most reliable technologies, our aseptic filling expertise is highly acclaimed by users for its high productivity?enabling long-term continuous operation?and its contribution to high-quality manufacturing.
We offer two primary bottle sterilization methods: the EB Bottle Sterilization System, which uses Electron Beam energy to sterilize PET bottles, and the Hydrogen Peroxide (H2O2) Bottle Sterilization System.

Features

• Enables lightweight bottle design.
• Eliminates thermal degradation of the product.
• Supports extended periods of continuous production.
• Allows for transportation and storage at ambient temperatures.
• Extends product shelf life.
• Offers greater flexibility in bottle design.

Bottle Sterilization Systems

Hydrogen Peroxide Bottle Sterilization System

Features

• Ensures reliable sterilization by uniformly spraying H2O2 inside and outside the bottle while minimizing chemical costs.
• Depending on sterilization conditions, the rinser can be downsized or eliminated, leading to a reduction in water consumption.
• By integrating a bottle molding machine into a synchronized system, the overall footprint can be significantly reduced.

EB Bottle Sterilization System

Features

• Directly irradiates the container with EB from a short distance to sterilize the sides.
• The rotation mechanism ensures full 360-degree irradiation, reliably sterilizing the entire container. It achieves a 6D reduction for B. subtilis and B. pumilus.
• As a chemical-free method, there is no risk of residual chemicals, and running costs are significantly lower compared to chemical methods.
• The compact sterilization unit significantly reduces the total system installation area.
• The self-shielded structure safely blocks X-rays. No specialized radiation officer is required, and the system can be operated with simple notification to authorities.

Fillers

Weight Filler

This filler controls the opening and closing of valves based on fill weight measured by load cells directly connected to the bottle base or neck gripper. It is highly versatile and compatible with various bottle sizes.

Features

• The liquid path features a simple, smooth structure for superior cleaning efficiency and sanitation.
• Corrects discrepancies between measured and actual weight caused by centrifugal force from machine rotation.
• Ensures consistently accurate filling regardless of rotation speed.
• Fill volume can be easily adjusted by entering values into the controller.

Flow Meter Filler

This filler ensures a constant fill volume by measuring flow rate using flow meters directly connected to the filling valves. It is compatible with a wide range of bottle sizes.

Features

• The simple, smooth liquid path ensures high cleaning effectiveness and exceptional sanitation.
• Equipped with an electromagnetic flow meter and a fill-volume correction system developed exclusively for filling machines, ensuring high-precision filling.
• Fill volume can be adjusted simply via the control panel, reducing time required for changeovers.
